Equipped with a dome-shaped 180° opaline diffuser for sharp image rendition and optimal peripheral visibility, this high-brightness single-pixel fixture can be easily assembled with other units to display low-resolution video files and graphic patterns on large surfaces. The next-generation ultra-resistant polycarbonate dome offers enhanced UV protection, ensuring long-lasting durability even in challenging outdoor environments, along with significantly improved luminance. Available with either RGBW or RGB LEDs in DMX-RDM or self-addressing control modes, GRAPH-i-CELL can be seamlessly integrated into existing architecture or stage backdrops, creating a vibrant and captivating ambiance. It can receive any graphic, video, or still image from a DVI media server via a DMX interface, with the configuration system capable of storing and triggering shows for striking visual effects. With its upgraded IP67 weather protection rating, GRAPH-i-CELL is suitable for almost any application, providing superior resistance to dust and water ingress.
Video
Colour configuration
High brightness RGB+W 4000K or RGB LEDs
Optical configuration
180°
Luminance
RGBW: 32900 cd/m2 / RGB: 12000 cd/m2
Pixel pitch
130 mm (minimum)
Resolution
49 pixel/m2 (maximum)
Input voltage
Main unit 48VDC. IP67 separate transformer 100-277VAC / 50-60Hz
Power consumption
15.3W max. (1 module full RGBW), 12W max. (1 module full RGB)
Ingress protection rating
IP67
Impact resistance rating
IK10
External operating limits
-40°C to 50°C / (-40°F to 122°F)
Warranty
5-year warranty
Accessories
Each Graph-i-Cell MUST always be purchased with power and data connection cables if the distance between the LED pixels is longer than 0.5m.
