Fitted with 12 premium quality high brightness power LEDs, PARADE L1 DW features an unquestionably powerful luminous flux with real uniform dynamic white colour coverage even on close-up installations for truly impressive wall grazing enhancement especially on large-scale architectural elements. A comprehensive selection of optical configurations and a vast choice of body finishes further enhance this linear profile tremendous flexibility and versatility. With a colour temperature between 2700K and 6500K, the pure white light spectrum intensity management creates a stunning visual rendering of warm tones, natural hues and cool shades altogether, thus offering an unmatched control over the creation of an expansive range of the white light chromatic scale for an even broader array of application purposes. The Polar Edition is equipped with an integrated de-icing system with electrically heated glass, which assures a comfortable functioning even in the utmost severe cold weather conditions.
Colour configuration
High brightness Dynamic White LEDs with an adjustable colour temperature range between 2700K and 6500K
Optical configuration
12° SP (Spot) 15° NA (Narrow) 25° ME (Medium) 48° WI (Wide) 59° EW (Extra wide) 14°X39° EL (Elliptical) 23°x38° WL (Elliptical wide) 19° (5° incline)x38° WW (Wall wash)
Max. Delivered lumen output
2221 lm
Max. lumen/Watt
117 lm/W
Input voltage
220-240VAC / 50-60 Hz
Power consumption
0.1A@230V / 19W
Ingress protection rating
IP67
Impact resistance rating
IK09
External operating limits
-40°C to 50°C / (-40°F to 122°F)
Polar Edition
Available on request.
Warranty
5-year warranty
Accessories
One Infrared Remote Control AL1321 must always be purchased for DMX/RDM versions, unless an RDM compatible control is used. More PARADE L-1 DW units can be controlled with one AL1321. PARADE L-1 DW must always be purchased with fixing brackets.
