Ideal for spot or flood lighting of building façades or large scale architectural structures, JASPER MK2 RGBW features a restyled chassis and hybrid cables to provide ease of installation, user-friendliness and clean setting-up. It meets the latest design requirements and aesthetical prerequisites demanding for powerful and efficient lighting solutions capable of delivering high level performances with a reduced power consumption. The combination of premium class RGBW LEDs, featuring either 4000K natural white or 3000K warm white, delivers the widest range of warm white shades and pastel tones assortment. This luminaire offers an expansive selection of different optical distributions. The Polar Edition features an integrated de-icing system with electrically heated glass, which assures a comfortable functioning even in the utmost severe cold weather conditions.
Video
Colour configuration
High brightness RGB+W 4000K or 3000K LEDs
Optical configuration
4° US (Ultra spot) 9° SP (Spot) 11° NA (Narrow) 23° ME (Medium) 43° WI (Wide) 69° EW (Extra wide) 125° UW (Ultra wide) 11°X41° EL (Elliptical) 22°x39° WL (Elliptical wide)
Max. Delivered lumen output
9029 lm
Max. lumen/Watt
46 lm/W
Input voltage
100-277VAC / 50-60 Hz
Power consumption
0.88A@230VAC / 195W max.
Ingress protection rating
IP66
Impact resistance rating
IK10
External operating limits
-40°C to 50°C / (-40°F to 122°F)
Optional feature
The fixture is also available in Class II, on request
Polar Edition
Available on request.
Warranty
5-year warranty
Accessories
Optional optical distribution and mounting accessories available for the utmost design flexibility
